아이소텍 ・ ISOTECH
975
GREYBODY SOURCE
When the high accuracy of the Gemini R is not necessary this product offers a cost effective solution for the calibration and testing of infrared thermometers.
The Greybody Model 975 gives fast accurate results with a larger sensing area. A temperature sensor sits just under the target surface and controls the temperature of the source. A custom designed surface sensor is used to set the controller calibration and a traceable certificate is supplied with each source.
- SPECIFICATION
Model | 975 GreyBody |
Temperature Range | 50°C to 350°C |
Display Resolution | 0.01°C – 50 to 99.99. 0.1°C – 100 to 350 |
Heating Time | 35 minutes |
Target Size | Ridged Plate, 70mm Diameter |
Stability | ±0.2°C |
Accuracy | ±2 |
Emissivity | >0.95 |
Power | 180 Watts |
Voltage | 100-130 or 208-240 VAC |
PC Interface | Included |
Dimensions | Height 115mm Width 230mm Depth 225mm |
Weight | 3.9kg |
How to order | Model 975 GreyBody Source – Please state voltage required. |
