아이소텍 ・ ISOTECH
Europa 4520
드라이블럭/배스
Europa 4520 Dry Block/Liquid Bath
주요 특징
- 온도범위: -45 to 250℃
- 교정공간: 35 × 160mm
- 모델 선택: EUROPA : -45 ~ 140℃ / VENUS : -35 ~ 140℃ / CALISTO : 30 ~ 250℃
- ISOCAL-6 계열: 온도블록, 항온조, ITS-90 고정점 셀, 적외선, 표면온도계 적용 가능
- 삽입블록: Standard, 고객 맞춤형
제품 소개
- 강하고 가벼운 외형
- 컬러 디스플레이
- 높은 정확도의 컨트롤러
- ±0.01°C 이상의 높은 안정도
- 0.001°C의 높은 해상도
- 3 input 채널 (2 PRT와 3 T/C 중 3개 설정)
- Ethernet과 웹서버를 통한 통신
- Auto Adjust (기준센서로 컨트롤러 설정)
- USB 데이터 이동
- Automatic Temperature Cycling ( PC or 컨트롤러)
I-CAL EASY 소프트웨어를 사용하여 최대 20개의 교정 포인트를 입력하고 센서 교정과 항온조 설정, 데이터 기록을 자동으로 할 수 있습니다.
ITS-90 또는 Calender Van Duesen 방정식을 이용하여 불확도 계산을 할 수 있고 기본적으로 포함되어 있는 내장 템플릿을 사용하거나 자신만의 인증서를 만들 수 있습니다.
Parameter | Model | ||
Europa 4520 | Venus 4951 | Calisto 4953 | |
Temperature Range | -45°C to 140°C1 | -35°C to 140°C2 | 30°C to 250°C3 |
ADVANCED Range | |||
Stability: Dry Block / Liquid Bath | ±0.01°C | ±0.01°C | ±0.02°C |
Display Resolution | 0.001°C over whole range | 0.001°C over whole range | 0.01°C over whole range |
Input Channel Accuracy: Thermocouple | E, J, K, N ±0.2°C @ 660°C R: ±0.6°C S: ±0.7°C @ 660°C T: ±0.2°C @ 150°C | " | " |
CJC Accuracy | ±0.35°C | " | " |
Input Channel Accuracy: RTD | ±0.05°C ±0.005% RDG | " | " |
BASIC / SITE Range | |||
Stability | ±0.03°C | ±0.03°C | ±0.03°C |
Display Resolution | 0.01°C from -19.99 to 99.99°C then 0.1°C: 0.01°C Over PC Interface | ||
COMMON Specifications | |||
Stability | Blackbody ±0.03°C Surface Sensor ±0.5°C ITS-90 Cells ±0.0005°C | " | " |
Unformity - Between Wells Dry Block Mode (Radial) | <0.008°C | <0.008°C | <0.02°C at 250°C |
Uniformity - Lower 40mm (Axial) Dry Block Mode | <0.040°C | <0.040°C | <0.25°C |
Uniformity - Radial Bath Mode | <0.02°C | <0.02°C | <0.011°C at 250°C |
Uniformity - Lower 40mm (Axial) as Liquid Bath | <0.026°C | <0.026°C | <0.02°C at 250°C |
Heating Time | -30°C to 140°C: 15 mins | -30°C to 140°C: 15 mins | 25°C to 250°C: 15 mins |
Cooling Time | 140°C to 0°C: 15 mins | 140°C to 0°C: 15 mins | 250°C to 30°C: 25 mins |
Calibration Volume | 35 x 160mm | " | " |
Standard Insert | 6 pockets, 2 x 4.5mm, 2 x 6.4mm, 1 x 8.0mm, 1 x 9.5mm diameter, all 157mm deep | " | " |
Insert Types | Choice of three - See Accessories | " | " |
Ethernet - supporting software and USB Host | " | " | |
CJC Accuracy | 0.35°C | " | " |
Dimensions | 384H (including handle) x 212W x 312D mm | " | " |
Power | 300 Watts | 150 Watts | 300 Watts |
Voltage | 115Vac or 230Vac 50/60Hz | " | " |
Weight | 14kg | 10.2kg | 8kg |
1 : In ambient of 20°C: Min. Temperature is 65°C Below Ambient, Absolute Minimum -55°C 2 : In ambient of 20°C: Min. Temperature is 55°C Below Ambient, Absolute Minimum -45°C 3 : In ambient of 20°C 4 : Dry Block Mode only: Comparing 4.5mm Well to Controller Display Value |
COMMON Specifications | |||
ADVANCED | SITE | BASIC | |
Digital Display of Set and Nominal Block Temperature | Yes | Yes | Yes |
PC Interface | Ethernet + USB Host | Serial | Serial |
Test Thermostats | Yes - Two Inputs | Yes - Single Input | No |
Independent Temperature Indicator for Reference Probe | Yes | Yes | No |
Additional Inputs for Units Under Test | Up to 3: Two universal inputs for PRT, Thermocouple or Process inputs and a further Thermocouple input |
No |
No |
Automatic Temperature Cycling | Yes | No | No |
Data Logging | Yes - Export to USB | No | No |
Offset Elimination | Yes - block can follow reference input | No | No |
Choose English, French, Italian or Spanish Language | Yes - on full colour display | No | No |
In Built Web Server | Yes | No | No |
Tamper Proof Data | Yes - Suitable for life science, automotive and aerospace applications |
No |
No |
상세정보 더 보기 (블로그) : https://blog.naver.com/geniuss7179/222125809855
